The Narda SignalShark 3310 is a hand-held Interference Analyser utilised for accurately measuring electrical field strength. The SignalShark 3310 includes a spectrum display with extremely fast measuring speed and other operating modes including Channel Power, Level Meter and Time Domain. The Signal Shark analyser features a wide range of diagnostic tools for detailed analysis of disturbance signals. The Signal Shark is supplied with 3 directional antennas and an active handle which allows automatic detection of the antennas pre-programming the correction factors within the Signal Shark. 6 rechargeable batteries are supplied with the Signal Shark allowing 9hrs of useage without charging.

Narda detects changes in an increasingly complex radio spectrum in real time and without gaps. This makes the SignalShark the perfect instrument/tool for real-time spectrum analysis, monitoring and localization

Where would this be used?

The Narda SignalShark 3310 would typically be used for Radiated Emissions testing. It is also an extremely handy tool for signal analysis, safety evaluation and can be used in conjunction with near field sniffer probes, E&H Field Antenna, Current Probes and more for investigatory work.

A high-performance, handheld real-time spectrum analyzer designed for precise EMF exposure evaluation, 5G signal profiling, and interference hunting. It offers 40 MHz real-time bandwidth, high sensitivity, and ruggedness (IP54) for field use,

Some of the additional functionalities of the Narda SignalShark 3310 include:

• Analog Demodulation.
• SCPI Remote Control - This allows the Narda Script Launcher to be installed.
• Spectrogram - Visual representation of the recorded spectrums versus time. Colours represent the signal level. The smallest selectable time resolution is 31.25μs. Detectors compress the high-speed real-time spectrums down to the selected time resolution.
• Level Meter including Compass values - Shows the results from an independent receiver path with channel filter.
• Isotropic Measurement: Compatible with 3-axis antennas for accurate, orientation-independent EMF measurements.
• Compliance Testing: Assesses safety boundaries, including 4G/5G, Wi-Fi, and broadcast signals.
• Interference Hunting: Identifies and locates interference sources with advanced persistence and spectrogram views.
• VITA 49 - Shows the basic measurement parameter settings while streaming I/Q data according to the Vita 49 standard.
• Automatic DF antenna control - Shows azimuth, elevation, DF quality, and omnidirectional RMS level derived from the Narda automatic DF antenna (ADFA).
• Horizontal Scan - Automatic direction finding of a signal source. Polar diagram with information on the field distribution and indication of direction towards the signal source for recognition of reflections and common channel interference. Numerical display of level, azimuth (angle from North), elevation (angle above horizon) and polarization. Extremely steep channel filters for clean separation of even closely spaced frequencies. Demodulation of USB, LSB, AM and FM with facility for recording.
• A 1/4inch UNC thread allows it to be mounted on to a variety of tripods / stands.
• Full automatic direction finding
• High dynamic reciever (HDR)
